Induction Motor Slot Combinations

Space harmonics fluxes are produced by the windings, slotting, magnetic saturation, inequalities in the air gap length. These harmonic fluxes induce voltages and circulate harmonic currents in the rotor windings. The interaction between the harmonic currents generated in the rotor and the harmonic fluxes results in the Harmonic torques, vibrations and the noise.

The air gap flux set up by the three phase stator windings carrying sinusoidal currents. The wave shape is non-sinusoidal in nature. According to Fourier series analysis, any non-sinusoidal flux is equivalent to the combination of a number of sinusoidal fluxes of fundamental and higher order harmonics. Since, the flux wave shape has half-wave symmetry, all even harmonics (2,4,6 ……) are absent in Fourier series.

A non-sinusoidal flux can be resolved into fluxes of fundamental and higher order odd harmonics (3, 5, 7, 11, 13, etc). The third harmonic flux wave produced by each of the three phases neutralizes one another. The resultant air gap flux is free from third harmonics and its multiples. This is because the third harmonics in the flux wave of all the three phases are in space phase, but differ in time phase by 120 degrees.

Harmonics Induction Torques

A 3 phase winding carrying a sinusoidal currents produces space harmonics of the order h = 6k ± 1, where k is a positive integer (1, 2, 3…..). The synchronous speed of the h^th harmonic is (1/h) times the speed of the fundamental wave. Space harmonic waves rotate in the same direction as the fundamental wave, if h = 6k + 1 and if h = 6k – 1 than it rotates in the opposite direction.

• The manual design of induction motor is the combination of lengthy calculations and special attention. The possible stator-rotor slot combinations for four pole.
• The reported results mainly focused on the slot and pole number combination of PM machines, 4 4. Zhu, “ Influence of slot and pole number combinations on voltage distortion in surface-mounted permanent magnet machines with local magnetic saturation,” IEEE Trans. Energy Conversion 30(4), 1460– 1471 (2015).

Space harmonic wave of the order h, is equivalent to a machine with the number of poles equal to (h x number of poles of the stator). Therefore, the synchronous speed of the h^th space harmonic wave is

Where,

• f = supply frequency
• P = number of poles of the stator

Thus, for the value of k = 1, a 3 phase winding will produce backward rotating fifth harmonic at the speed of (1/5) of the synchronous speed and forward rotating seventh harmonic rotating at a speed of (1/7) of the synchronous speed. These harmonics alone will have an effect on the operation of the motor.

The speed torque characteristics of the fundamental flux and the fifth and seventh space harmonic flux are shown below.

The fifth harmonic torque opposes the fundamental component torque as the fifth harmonic flux rotates in the opposite to the rotation of the rotor. Thus, the fifth harmonic flux produces a braking torque. The seventh harmonic flux rotates in the same direction as that of the fundamental flux. Hence, the resultant torque speed characteristic will be the combination of the fundamental fifth and seventh harmonic characteristic.

The resultant torque speed characteristics have two dips, one near (1/5) of the synchronous speed and the other near (1/7) of the synchronous speed. The dip near (1/5) of the synchronous speed occurs in the negative direction of the motor rotation.

The motor will accelerate to the point L, which is the interaction between the load torque characteristic and the motor torque-speed curve. This motor torque is developed because of the fundamental flux alone. The load torque curve intersects the motor torque speed characteristics at the point A this is because of the presence of the seventh harmonics flux torque.The seventh harmonic flux torque curve has a negative slope at the point A.

Solution: Slot per pole: 3.3 =9 For this machine design configuration, the suitable stator and pole combinations are: 18 stator slots with 2 poles 36 stator slots with 4 poles and goes on depending on your machine size.

The motor torque falls below the load torque. At this stage, the motor will not accelerate up to its normal speed, but will remain running at a speed which is nearly (1/7) of its normal speed, and the operating point is A. This tendency of the motor to run at a stable speed as low as one seventh of the normal speed Ns. In this condition the motor is unable to pick up its normal speed is known as crawling of the motor.

Crawling can be reduced by reducing fifth and seventh harmonics. This can be done by using a chorded or short pitched winding.

Introduction

This article reviews the techniques to mitigate noise and vibrations due to magnetic forces in electrical machines (electromagnetically-excited noise and vibrations) based on EOMYS ENGINEERING consulting experience. The content of this article is taken from EOMYS technical trainings on electric motor NVH.

Noise and vibration control techniques of e-motors can be classified in three types:

• reduction of the structural response independently of the electromagnetic excitations
• reduction of the electromagnetic excitations independently of the structural response
• reduction of the number of resonances occuring between electromagnetic excitations and structural modes

The most efficient acoustic noise mitigation techniques are based on the cancellation of the harmonic electromagnetic excitations responsible for vibration and noise.

All these noise control techniques can be applied at early electromagnetic design stage using MANATEE software for the fast calculation of noise and vibrations in electric motors.

Choice of the topology

There is no unique choice for a low noise & vibration machine, but some topologies are more challenging in terms of NVH. This also depends on the application constraints (e.g. power density, fixed speed or variable speed application).

Outer rotor topologies (also called outrunner motor if it is a brushless DC motor) can lead to higher noise & vibration due to rotor yoke lower stiffness compared to an outer stator topology. Fractional-slot winding or more particularly concentrated or tooth winding might lead to higher acoustic noise & vibrations compared to integral distributed winding due a higher number of wavenumbers in the armature field and the possible presence of subharmonics.

The best armature winding is the one creating the most sinusoidal mmf, so the double-layer, shorted-pitch, distributed integral winding. For permament magnet rotors, the best magnet architecture is also the one creating the most sinusoidal rotor mmf, so either Hallbach configuration for surface magnets, or multi-barriers V-shape interior magnets with bread-loaf pole shapes (also called sinusoidal field poles).

MANATEE software can be used to calculate the NVH behaviour of all types of radial flux electric machines, including interior (buried), inset and surface permanent magnet synchronous machines, squirrel cage induction machines, outer rotor and inner rotor electrical machines.New topologies can be easily implemented upon request.

Machine SPMSM_015 Topology

Asymmetries

An electric machine designed to have low harmonic distortion rate magnetomotive forces (e.g. an IPMSM with double-layer shorted-pitch distributed-winding, and V-shaped magnets) can reveal noisy due to manufacturing & assembly tolerances which introduce asymmetries.

Static and dynamic eccentricities increase the spectral density (wavenumbers & frequencies) of harmonic magnetic forces.

Mass & stiffness asymetries (and low number of teeth, introducing discrete distribution of stiffness along yoke) increase the modal density and number of resonances at variable speed.

Uneven airgap modulates magnetic forces and increases the number of different force wavenumbers, increasing the number of structural resonances.

Effect of asymmetries on electromagnetically-excited noise using MANATEE software (left: no asymmetry, right: with asymmetries)

To lower noise and vibrations the machine should be magnetically and geometrically symmetrical:

• low tolerance on eccentricities and misalignments
• low tolerance on lamination roundness
• low tolerance on magnet magnetization dispersion
• low tolerance on magnet position in slots

MANATEE software can consider the NVH effect of radial and conical eccentricities, as well as uneven airgap, demagnetization, and pole displacement.

Choice of the pole / slot / phase numbers

Generalities

Increasing the number of slot per pole per phase reduces the harmonic density of airgap flux and resulting magnetic forces.

Increasing the number of pole pairs gives a lower electromagnetic yoke height, thus higher vibration & noise. However, the lowest force wavenumber is also given by the Greatest Common Divider between stator slot and pole numbers in Permanent Magnet Synchronous Machines: increasing p also potentially increases GCD(Zs,2p), resulting in lower electromagnetic vibrations.

These examples show that changing the slot/pole/phase combination involves different electromagnetic and vibro-acoustic opposite effects, so numerical simulation with MANATEE software is advised.

Case of induction machines

The number of rotor slots Zr is a key design parameter as it influences both wavenumbers and frequencies of Maxwell harmonic forces. Pole/slot interactions in induction machines create exciting forces at multiples of the rotor slot passing frequency.

Some empirical rules to choose the slot / pole combination are given in many electrical engineering books such as [1-5]. However these rules are continuous, they do not reflect correctly the discrete nature of harmonic force wave and do not account for the stator natural frequencies nor the speed range of the machine. The use of such empirical rules should be avoided and numerical simulation is advised for instance with MANATEE software. An example of the discrete evolution of electromagnetically-excited noise with rotor slot number is given in this tutorial.

Effect of the rotor bar number on the maximum sound level emitted by a variable-speed induction motor (MANATEE software output)

When both stator slot and rotor slot numbers Zs & Zr are even integers, Maxwell force harmonics only contain even force wavenumbers for integral windings, thus avoiding Unbalance Magnetic Pull.

The number of rotor and stator slots should never be equal, otherwise strong pulsating radial and tangential force waves appear in the machine, creating high air-borne noise the stator breathing mode and potentially high structure-borne noise due to torque ripple.

Contrary to Permanent Magnet Synchronous Machines where some global rules on slot / pole combination can be relevant, the case of induction machines is more complex. Ideally one should avoid the presence of high magnitude (due to first rank of permeance), 'low' wavenumber so in particular one should avoid

• [Zr-Zs =0, 2 or 4
• Zr-Zs-2p =0, 2 or 4
• Zr-Zs+2p =0, 2 or 4

Relying only these rules of thumbs for the design of an electric machine is suboptimal and risky. Again variable speed calculation of electromagnetically-excited noise is advised using MANATEE software.

Case of synchronous machines

When stator slot is an even integers, Maxwell force harmonics only contain even force wavenumbers for integral windings, thus avoiding Unbalance Magnetic Pull. More precisely UMP only exists if Zs-2p =1.

Maximization of LCM(Zs,2p) increases the frequency of open-circuit pulsating (wavenumber r=0) radial and tangential force harmonics (in particular cogging torque and average radial force).

Minimization of GCD(Zs,2p) reduces the magnitude of open-circuit pulsating (wavenumber r=0) radial and tangential force harmonics (in particular cogging torque and average radial force).

Maximization of GCD(Zs,2p) increases the non-zero wavenumbers of open-circuit (and probably also partial load) magnetic forces, thus potentially reducing noise and vibration levels.

Simiarly to induction machines, one should avoid the presence of high magnitude (due to first rank of permeance), 'low' wavenumber so in particular one should avoid

• [2p-Zs =0, 2

The 12s10p PMSM machine is known to be prone to high vibration and noise because 2p-Zs =2: in open-circuit and under commutation, many force harmonics have a wavenumber 2 and can resonate with the stator elliptical mode.

As you can see some of these rules of thumb are contradictory and changing the slot number also changes the magnitude of permeance harmonics, so full NVH variable speed simulation is recommended with MANATEE software.

Choice of the winding

The ideal winding gives a sinusoidal mmf, it has an infinite number of phases ( no « belt harmonics »), an infinite number of slots (no « slot harmonics » or preferably no « step harmonics ») or no slot at all ('airgap winding').

To avoid Unbalanced Magnetic Pull the winding-induced mmf should never have two harmonics separated of 1.

Concentrated winding / tooth-winding / fractional winding have the largest mmf distortion factor, however if properly designed they do not generate noise & vibrations.

Shorted-pitch distributed windings gives the smoothest magnetomotive force.Short-pitching or chording technique consists in having several winding layers and shifting the winding pattern in each layer. The chording cannot reduce the largest mmf step harmonics at Zs-p and Zs+p space harmonics.The coil pitch Y (in slots, between 0 and Zs/(2p)-1) can be chosen as (5/6) Zs/(2p) to reduce the stator mmf space harmonics 5p and 7p.

This MANATEE software tutorial explores the effect of short pitch on magnetic noise of an induction motor.

Example of an AC winding distribution (MANATEE output)

All winding types can be modelled in MANATEE software, using automated winding algorithms, winding connection matrix or Koil winding freeware. Dedicated post-processing allow to analyze the armature field harmonic content are available (see for instance plot_smmf_space).

Skewing

Skewing consists in rotating a 2D slice of the electrical machine along its rotation axis in order to smoothen the average field and cancel out some specific harmonics. Skewing can be applied to stator, rotor or both.

Stator skew is generally linear, and rotor skew depends on machine topology (linear for squirrel cages, stepped-skew or linear for permanent magnets).

Skewing can cancel a given force harmonics when considering its average longitudinal value (DC component). However, it also introduces an axial magnetic force variation and can therefore excite longitudinal structural modes of the stator and rotor structures. It can also create an additional axial thrust.

The skewing angle and the part to be skewed (rotor or stator) depends on the magnetic force harmonic to be cancelled.

The best skewing angle might be different when trying to minimize torque harmonics or radial force harmonics, and the best skewing angle might depend on the load condition.

This task can be carried using MANATEE simulation environment where all types of skew shape can be modelled. This tutorial of MANATEE shows how to calculate the effect of rotor skew on torque ripple and acoustic noise.

Effect of the rotor skew rate on the maximum sound power level radiated by a variable-speed PMSM (MANATEE software output)

Pole magnetization

Playing on the magnetization pattern allows to tune the rotor mmf harmonic content and thereof influence the vibroacoustic behaviour of the electric motor.Hallbach pattern lowers the spatial harmonic content of mmf but is expensive to manufacture.Shaping the magnetization pattern and optimizing the pole dimensions to minimize some specifics harmonics involved in noise generation is not sufficient to obtain a low vibration and noise design, as some other harmonics may increase during this process, creating new resonances.

A full electromagnetic and NVH simulation is recommended with MANATEE software. MANATEE software includes radial, parallel and Hallbach magnetization patterns in both subdomain magnetic models and finite element models.

Pole shaping

Magnet / pole shoe shaping allows to « tune » the rotor mmf harmonic content and thereof the vibroacoustic behaviour of the electric machine.

As both constructive and destructive interference occurs, cancelling a given magnet mmf space harmonic responsible for acoustic noise does not necessarily reduce noise as it can increase other force harmonics.For wound rotor synchronous machines the pole arc curvature has large influence on noise.Due to the combined effect of radial and tangential forces on radial vibrations and noise, simulation with MANATEE software is recommended.MANATEE sensitivity tools and optimization tools can be used for instance to find the best magnet pole arc to pole pitch ratio minimizing both torque ripple and acoustic noise.

Pole width and position

The pole widths or pole positions (pole shifting technique) of a synchronous machine can also be modulated to tune the rotor magnetimotive force spectrum content. Other pole displacement techniques to reduce cogging torque and zero-th average radial force include axial and radial pole-pairing technique (association of two different pole shapes to cancel a given harmonic).

Pole displacement techniques should be applied very carefully and should not focus only on the minimization of torque ripple / cogging torque, as noise and vibrations are also produced by higher wavenumber tangential and radial force harmonics. Simulation with MANATEE software is recommended.

Slot and tooth shape / position

Stator slot shapes or positions can be modulated to spread the permeance spatial spectrum or reduce / cancel a specific harmonic involved in noise and vibration generation.Slot-pairing (teeth pairing) techniques can reduce cogging and average radial forces by cancelling the first component only at LCM(Zs,2p)fR.

Notches

Notches (sometimes called circumferential slits, auxiliary slots, dummy slots, or grooves) consists in removing some part of the magnetic sheet material to modulate the airgap reluctance.If properly sized, notching can artificially increase the permeance wavenumber, as if the slot number was increased.The average airgap is increased due to notches (increase of Carter coefficient) so it may slightly reduce the electromagnetic performances.The introduction of notches can also increase the local saturation level.Similarly to skewing, the effect of notches can strongly depend on the operating point.

Simulation with MANATEE software is recommended. This MANATEE tutorial demonstrates how to use rotor notches to reduce the acoustic noise of an induction machine.

FEMM submodel to calculate a rotor notch effect

Stator slot opening optimization

The permeance harmonics are due to reluctance variation along the airgap, and slotting effects are a source of permeance harmonics at multiples of slot number. Slot to tooth opening ratio can reduce some of the permeance harmonics (similarly to pole pitch to pole arc ratio for the rotor mmf), but it is influenced by saturation and sometimes several slotting harmonics are involved in noise generationIf the first stator slot harmonic (ks=1) is responsible for a force wave in a machine - ex: PMSM with Zs=12 and p=5, a harmonic force exists with r=(1*Zs-1*p)-(0+1*p)=2 - closing the slot will cancel the permeance harmonic.

In practice slots cannot be geometrically closed due to winding process (a minimum slot opening is often required to pass needle and strand, or to use tooth tip as a support for winding) and magnetically closed due to saturation.

Optimal slot design can be carried using MANATEE software for the prediction of electromagnetic noise and vibraitons.

Magnetic wedges

Magnetic wedges allow to reduce the magnetic reluctance change in the slot opening, reducing flux density slotting harmonics and therefore cogging torque and all magnetic force harmonics related to permeance harmonics.Due to low relative permeability of commercial wedges (max 10) the effect on noise is limited (max 3 dB).The impact of magnetic wedges on e-motor vibroacoustics can be studied within MANATEE e-NVH software.

Induction Motor Slot Combinations Car Bodies

Airgap increase

Electromagnetic performances (e.g. efficiency) is directly affected by airgap width so one must check that the impact on performance and control does not worsen the noise (e.g. due to higher current).Airgap increase can affect differently magnetic force harmonics, and the effect on magnetic noise is quite limited.The effect of airgap width can be easily studied using MANATEE software parameter sweep environment.

Flux barriers

Flux barriers or pockets in stator yoke and teeth, or rotor yoke and teeth can modify the airgap flux harmonic content and magnetic force magnitude due to local saturation effects.It generally significantly affects the machine performances (increase of leakage inductance, reduction of torque) so it must be used carefully.

Effects of flux barrier dimensions on the harmonic content of airgap flux obtained with MANATEE software

MANATEE software can be used to size the flux barriers as shown in this validation article.

Control

Case of induction machines

Magnetic noise is linked to magnetizing flux and not to torque, it is possible to increase torque with constant flux and noise.MANATEE software simulation allows to find the trade-offs between vibroacoustic and electrical performances.

Case of synchronous machines

Induction Motor Slot Combinations Car Parts

Current angle or load angle has a strong influence on average magnetic force magnitude.The load angle can influence the magnitude of higher time harmonics of wavenumber r=0 tangential & radial forces. The load angle evolution of force harmonics depends on their frequency and spatial order. Iq changes both pulsating radial and tangential force harmonics (torque), while Id mainly changes pulsating radial force harmonics. NField weakening (negative Id ) may reduce pulsating radial force ripple while increasing tangential force ripple.

A detailed sensitivity analysis including structure-borne and air-borne noise under MANATEE software is advised to study the tradeoffs between optimal control for efficiency and optimal control for noise reduction.

Harmonic current injection

Generalities

A given vibration harmonic can be compensated by injecting additional harmonic currents, depending on the magnetic force wavenumber to be cancelled.As the current modulates the spatial harmonics of mmf winding functions, the current injection cannot create new wavenumbers than those already present in the magnetic forces. Current injection introduces new time harmonics and therefore new force harmonics (cf PWM lines), one must check that this does not worsen the vibration or noise level nor torque ripple.

High frequency noise is more difficult to damp with current injection (requires higher controller bandwith & higher reactance can induce higher DC bus voltage)Harmonic injection at 6f in DQH frame can damp r=0 pulsating harmonic force at 6f.

Synchronous machines

For synchronous machines, pulsating radial / tangential force waves magnitude at frequencies proportional to LCM(Zs,2p)fs/p can be damped using current injection. For radial force damping either Id or Iq harmonic injection theoretically works.

Induction machines

Radial force harmonics of wavenumbers 0 and 2p can be damped using current injection. For other wavenumbers, a detailed study must be carried.MANATEE software includes a special e-NVH mitigation environment to optimize harmonic current injection with respect to acoustic noise and torque ripple.

Switching strategies

Generalities

Voltage inverter switching strategies determine phase voltage harmonic content and resulting phase current spectrum. Supply voltage harmonics contain harmonics linked to the inverter Pulse Width Modulation (PWM) switching frequency (ex: fswi, 2fswi) and harmonics linked to fundamental (ex: 5f, 7f). The largest voltage, current, forces, vibration and noise harmonics can occur around once or twice the switching frequency depending on the PWM strategy and torque/speed operating point of the machine.

A voltage harmonic f creates a harmonic current f which in turn generates magnetic forces and vibration waves f+fs, 2p and f-fs, 0 where fs is the fundamental electrical frequency.

Increasing the switching frequency generally reduces the acoustic noise (dBA reduction above 2.5 kHz), in some cases it can be chosen out from human’s ear sensitivity. However, it significantly increases inverter losses so again tradeoffs between efficiency and NVH must be analyzed, which can be carried under MANATEE software.

Spread spectrum strategies

Spread spectrum principle is already used in aerodynamic noise (uneven blade spacing of fans). The same principle is used in randomized switching strategies.Such strategies may lower the maximum dBA level, but they result in a wider excitation spectrum which can lead to new resonances depending on damping and natural frequency position with respect to exciting forces. Finally, random strategies can significantly affect sound perception and a detailed sound quality study is advised.MANATEE software includes some sound quality metrics to study this effect.

PWM strategies

There exist a number of PWM strategies such as SPWM, SVPWM, DPWM0, DPWM1, DPWM2, DWPM3, DPWMmin, DPWMmax, GDPWM.These commutations strategies have been developed to maximize converter output and efficiency, and they change the excitation voltage spectra and resulting sound power level as well as sound quality metrics.All these PWM strategies are already implemented in MANATEE e-NVH software, which also includes sound quality metrics to optimize power electronics switching strategy.

Structural response

Lower noise & vibration can be achieved by putting natural frequencies further away from magnetic excitations.Stator yoke can be stiffened to reduce vibration and noise levels ; in this case one must check that the natural frequency change due to the yoke geometry change does not compensate noise and vibration reduction due to yoke stiffening.

MANATEE software can be used to automatically study the effect of lamination shape on acoustic noise.

Other techniques to play on both air-borne and structure-borne noise include

• optimize yoke geometry
• optimize coupling between lamination and housing
• optimize slot stiffness (winding material, spacers)
• optimize stator fixation method in casing

MANATEE software coupled to FEA can be used to optimize these couplings and find a way to reduce the overall noise levels considering all transfer paths.

Damping

Increasing damping is one of the most efficient techniques to reduce noise and vibration of electric machines. It includes:

• optimization of impregnation process (VPI, potting, dipping): materials, curing process, operating temperature
• use of higher damping magnetic sheets
• use of interlamination damping
• use of viscoelastic materials

References

[1] J.F. Gieras, C. Wang and J.C. Lai, Noise of polyphase electric motors, CRC Press, 2005.

[2] P.L. Timar, Noise and vibration of electrical machines, Elsevier, 1989.

[3] S.J. Yang, Low noise electrical motors, Clarendon Press, Oxford, 1981.
